PTFE daim kab xev-Wrapped Hlau
Huaying PTFE daim kab xev-Wrapped Hlau yog tsim los ntawm Huizhou Huaying Electronic Technology Co., Ltd. Ob peb xyoos dhau los, peb lub tuam txhab tau tsim kev koom tes nrog rau Shenzhen Research Institute ntawm Huazhong University of Science thiab Technology, ua hauj lwm ua ke ntawm technologies breakthroughs. Ntau cov qauv kev lag luam tshiab tam sim no suav nrog cov txiaj ntsig ntawm lawv txoj kev tshawb fawb thiab kev tsim kho. Qhov kev ua haujlwm thev naus laus zis no tsis sib haum los ntawm tsuas yog hais txog lwm lub tuam txhab. Ua tsaug rau peb txoj kev cog lus rau kev siv tshuab thiab cov khoom zoo, ntau tus neeg muas zaub tau kos rau peb cov khoom. Koj tos dab tsi? Koom nrog peb hnub no!
Cov txheej txheem tsim khoom
Thaum nws los txog rau cov txheej txheem tsim khoom rau Huaying PTFE daim kab xev-Wrapped Hlau, peb cov kab ntau lawm yog lub xeev-ntawm-tus-kos duab. Piv txwv li, peb CT280 / CT285 nws tus kheej-nplaum hlau tuaj yeem lis cov kab uas hla ntawm 0.25mm txog 1.0mm nrog kev ua haujlwm siab. Txawm tias cov xov hlau me me li 0.10mm, peb tuaj yeem tsim lawv ntawm tus nqi siab thiab ruaj khov. Tib yam siv rau ob qho tib si kub-melt daim kab xev-pob thiab kub-kub Mylar daim kab xev-pob xov hlau, uas muaj tib lub xov hlau inch ntau thiab ntau lawm ceev. Txhua lub xaim yog tswj tau zoo, tshem tawm cov kev sib txawv tsis sib xws lossis txoj kab uas hla.
Kub-kub Resistance
Huaying PTFE Daim kab xev-Wrapped Hlau yog tus thawj coj tiag tiag hauv kev ua haujlwm siab kub. Txawm tias thaum raug kub siab rau lub sijhawm ntev, nws qhov kev ua tau zoo tseem tsis cuam tshuam. Nws tshwj xeeb toughness ua rau nws resistant rau me ntsis strain los yog compression. Tsis tas li ntawd, nws adheres yooj yim, ua kom muaj kev ruaj ntseg tuav thaum lub sij hawm sib dhos tsis tas yuav muaj cov nplaum ntau dhau. Qhov tseem ceeb, nws lub zog dielectric yog qhov siab dua li ntawm ib qho khoom siv insulated hlau, ua kom muaj kev ruaj ntseg hluav taws xob ntau dua.
Customized Product Services
Peb muab customized Huaying PTFE daim kab xev-Wrapped Hlau rau cov neeg siv khoom tshwj xeeb. Piv txwv li, cov neeg siv khoom yuav xav tau ib qho xim rwb thaiv tsev kom paub qhov txawv ntawm cov xov hlau nrog cov haujlwm sib txawv, lossis lawv yuav xav tau cov xov hlau uas muaj cov kab tshwj xeeb lossis cov khoom siv rwb thaiv tsev kom tau raws li qhov chaw ua haujlwm ntawm lawv cov khoom siv. Raws li ntev raws li tus neeg siv khoom muab cov kev xav tau tshwj xeeb, pab pawg R & D yuav tsim cov kev daws teeb meem raws li qhov xav tau thiab tsim cov khoom lag luam customized uas ua tau raws li cov neeg siv khoom xav tau.
| Tus neeg xyuas pib (mm) | zuag qhia tag nrho txoj kab uas hla (mm) | daim kab xev dav (mm) | Sib tshooj tus nqi | Ntim ntev (M / axis) | Tus coj tsis kam (20 ℃) (Ω/km) | Ntaus tooj liab bar rau tiv taus hluav taws xob AC/KV | |||
| Tus coj txoj kab uas hla | Tso cai kam rau ua | yam tsawg kawg nkaus tus nqi | phiaj tus nqi | Qhov siab tshaj plaws | |||||
| 0.10 × 30 | ± 0.008 | 0.704 | 0.804 | 0.904 | 6 ± 0.2 | ≥110% | 2000 | ≤86.7 | 4 |
| 0.10 × 40 | ± 0.008 | 0.807 | 0.907 | 1.007 | 6 ± 0.2 | ≥110% | 1000 | ≤65 | 4 |
| 0.10 × 50 | ± 0.008 | 0.898 | 0.998 | 1.098 | 7 ± 0.2 | ≥110% | 1000 | ≤ 52.0 | 4 |
| 0.10 × 60 | ± 0.008 | 0.98 | 1.08 | 1.18 | 7 ± 0.2 | ≥110% | 1000 | ≤ 43.3 | 4 |
| 0.10 × 70 hli | ± 0.008 | 1.055 | 1.155 | 1.255 | 8 ± 0.2 | ≥110% | 1000 | ≤37.1 | 4 |
| 0.10 × 80 hli | ± 0.008 | 1.13 | 1.23 | 1.33 | 8 ± 0.2 | ≥110% | 1000 | ≤32.5 | 4 |
| 0.10 × 90 hli | ± 0.008 | 1.19 | 1.29 | 1.39 | 8 ± 0.2 | ≥110% | 800 | ≤ 28.9 | 4 |
| 0.10 X 100 hli | ± 0.008 | 1.253 | 1.353 | 1.453 | 8 ± 0.2 | ≥110% | 800 | ≤ 26.0 | 4 |
| 0.10 X 110 hli | ± 0.008 | 1.312 | 1.412 | 1.512 | 8 ± 0.2 | ≥110% | 800 | ≤ 23.638 | 4 |
| 0.10 X 120 hli | ± 0.008 | 1.369 | 1.469 | 1.569 | 8 ± 0.2 | ≥110% | 800 | ≤ 21.668 | 4 |
| 0.10 X 130 hli | ± 0.008 | 1.423 | 1.523 | 1.623 | 9 ± 0.2 hli | ≥110% | 800 | ≤ 20 | 4 |
| 0.10 X 140 hli | ± 0.008 | 1.475 | 1.575 | 1.675 | 9 ± 0.2 hli | ≥110% | 800 | ≤18.573 | 4 |
| 0.10 X 150 hli | ± 0.008 | 1.525 | 1.625 | 1.725 | 9 ± 0.2 hli | ≥110% | 800 | ≤17.335 | 4 |
