Ob-Mylar Insulated Hlau

Huaying Ob-Mylar Insulated Hlau yog tsim nyob rau hauv Suav teb los ntawm Huizhou Huaying Electronic Technology Co., Ltd. Koj puas paub lub tuam txhab no? Lawv muaj lub koob npe nrov zoo hauv kev lag luam thiab ua qhov tseem ceeb ntawm cov khoom zoo. Lawv tau tsim kom muaj kev tswj xyuas nruj thiab ua tiav kom ua tiav thiab ua tiav lav cov khoom zoo thoob plaws hauv tag nrho cov txheej txheem. Qhov no tau nyiam ntau tus neeg koom tes hauv kev lag luam nrhiav kev sib koom tes thiab kev sib koom tes ua haujlwm. Koj tuaj yeem xaiv peb cov khoom nrog kev ntseeg siab.

Xa lus nug

Product Description

Cov khoom siv sab hauv

Huaying Double-Mylar Insulated Wire nta cov qauv tsim sab hauv. Tsis yog ib qho loj-haum-tag nrho cov qauv tsim, Huaying muaj cov khoom tshwj xeeb uas haum rau cov kev xav tau tshwj xeeb. Piv txwv li, muaj CT-280B / CT-285, plaub-txheej insulated hlau nrog kev sib xyaw ntawm PET, PTE, PA, thiab PET daim kab xev; lwm yam nrog peb txheej ntawm ETFE thiab ib txheej ntawm daim kab xev; thiab thaum kawg, kub-kub insulated hlau nrog polyurethane thiab PI daim kab xev. Cov qauv sib txawv haum rau kev siv sib txawv. Piv txwv li, qhov kub thiab txias insulated hlau yog qhov zoo tagnrho rau cov khoom siv kho mob, qhov kub thiab txias yog qhov tseem ceeb, tso cai rau cov neeg siv khoom kom pom tseeb cov khoom uas haum rau lawv cov kev xav tau.

Product Environmental Yam ntxwv

Peb Huaying Double-Mylar Insulated Wire siv kev saib xyuas tshwj xeeb los tiv thaiv ib puag ncig! Los ntawm kev xaiv cov khoom siv raw mus rau kev tsim khoom, txhua kauj ruam yog nyob ib ncig ntawm "ntsuab thiab qis-carbon". Piv txwv li, cov ntaub ntawv PET thiab ETFE siv nyob rau hauv lub rwb thaiv tsev txheej tsis yog tsuas yog saum toj kawg nkaus, tab sis kuj ua raws li ROHS thiab REACH halogen-dawb cov qauv, tsis muaj teeb meem hnyav hlau xws li txhuas thiab mercury. Txawm hais tias cov khoom raug muab pov tseg thiab rov ua dua tshiab, nws tsis ua paug av lossis dej. Tsis tas li ntawd, kev cob qhia kev tsim khoom siv cov khoom siv txuag hluav taws xob, thiab cov dej khib nyiab thiab cov pa tawm ua kom tau raws li lub teb chaws tus qauv, tsis txhob tshaj lawv. Cov tuam txhab lag luam uas tseem ceeb rau kev tsim khoom lag luam ntsuab, xws li cov hauv tsev ntse thiab cov menyuam yaus cov khoom siv hluav taws xob, tuaj yeem siv peb cov xaim kom tsis tsuas yog dhau ib puag ncig cov ntawv pov thawj tab sis kuj ntxiv cov ntawv "eco-friendly" rau lawv cov hom, uas yog cov neeg tau txais txiaj ntsig zoo.

Khoom Siv Lub Sijhawm Stability

Peb Huaying Ob-Mylar Insulated Hlau yog qhov ruaj khov! Txawm tias siv mus ntev thiab ntau yam hnav thiab tsim kua muag, nws qhov kev ua tau zoo tseem tsis hloov pauv ntau. Siv kev laus, piv txwv li. Ordinary insulated hlau tuaj yeem ua nyuaj thiab txawm tawg tom qab peb mus rau tsib xyoos vim oxidation thiab hloov pauv kub thiab av noo. Tab sis peb cov hlau txawv. Cov khoom siv rwb thaiv tsev muaj cov qauv los tiv thaiv kev laus, thiab kev tiv thaiv tshwj xeeb yog siv los ntawm cov khaubncaws sab nraud povtseg. Cov kev ntsuam xyuas kev laus dhau los tau pom tias nyob rau hauv ib txwm siv, nws tswj kev ua haujlwm ruaj khov rau 8 mus rau 10 xyoo, ze li ob npaug ntawm lub neej ntawm cov kab hluav taws xob zoo tib yam.

Khoom Specifications

Hluav taws xob Tus coj	tag nrho txoj kab uas hla phiaj tus nqi	Tus coj tsis kam (20 ℃) (Ω/km)	Hluav taws xob Tus coj	tag nrho txoj kab uas hla phiaj tus nqi	Tus coj tsis kam (20 ℃) (Ω/km)
0.25	0.59	370.20	0.50	0.84	89.95
0.26	0.6	358.40	0.55	0.89	78.15
0.27	0.61	331.40	0.60	0.94	65.26
0.28	0.62	294.10	0.65	0.99	55.31
0.29	0.63	285.70	0.70	1.04	47.47
0.30	0.64	254.00	0.75	1.09	41.19
0.32	0.66	222.80	0.80	1.14	36.08
0.35	0.69	185.70	0.85	1.19	31.87
0.37	0.71	165.90	0.90	1.24	28.35
0.40	0.74	141.70	0.95	1.29	25.38
0.45	0.79	112.10	1.00	1.34	23.33
