UL 1180 Teflon hlau

Qhov no Huaying UL 1180 Teflon Hlau yog muab los ntawm Huizhou Huaying Electronic Technology Co., Ltd. Cia peb pib tham txog lub zog ntawm lub tuam txhab no. Lawv cov kev txhawb nqa tsis yog ib lub koom haum me xwb! Peb ua haujlwm ncaj qha nrog lub koom haum tshawb fawb Shenzhen ntawm Huazhong University of Science thiab Technology, ib lub koom haum tshawb fawb hauv Suav teb. Ua ke, peb tau tsim cov tub ntxhais rwb thaiv tsev hlau thev naus laus zis, ua tiav qhov kev ua tiav tiag tiag. Qhov kev mob siab no yog tom qab cov khoom no, uas yog vim li cas nws thiaj li nrov nrog cov neeg siv khoom - nws tsis yog kev khav theeb xwb!

Xa lus nug

Product Description

Khoom Rwb thaiv tsev muaj peev xwm

Qhov no Huaying UL 1180 Teflon Hlau siv peb txheej txheej txheej. Qhov no tsis yog ib qho yooj yim stacking ntawm cov ntaub ntawv; txhua txheej muaj qhov sib txawv. Cov txheej txheej sab hauv cov khoom yog tshwj xeeb tawv, nruj nreem qhwv ib ncig ntawm tus neeg xyuas pib. Txawm hais tias rov khoov dua thaum txuas, nws tiv thaiv kev tawg. Cov txheej nruab nrab thiab txheej txheej yog inherently tshav kub-resistant thiab corrosion-resistant, muab ib tug du, tsis-grainy xav. Lub rwb thaiv tsev tseem ruaj khov rau hauv qhov chaw, kom ntseeg tau tias txawm pinching thiab rubbing. Txawm tias siv mus ntev, tsis muaj kev txhawj xeeb ntawm kev laus los yog tev, tsim kom muaj qhov ruaj khov, ruaj khov.

Non-stick Surface

Thaum lub sij hawm tsim cov txheej txheem, Huaying UL 1180 Teflon Hlau resists roj thiab plua plav, yooj yim tshem tawm nrog lub tshuab maj mam. Yog tias cov stains tawv tawv tau txais ntawm peb cov khoom, tsuas yog so nrog daim ntaub qhuav lossis dej me ntsis rau kev ntxuav tam sim ntawd, tshem tawm qhov xav tau kev tu siab heev. Cov cuab yeej uas tsis yog-stick no kuj tseem muaj txiaj ntsig zoo thaum lub sijhawm sib dhos, tiv thaiv cov xov hlau los ntawm kev nplaum thiab tangling, ua rau kev sib tw smoother thiab txhim kho kev sib dhos zoo. Tsis tas li ntawd, thaum lub sijhawm ua haujlwm ntawm cov cuab yeej siv, cov xov hlau tsis txhob muaj kev sib txhuam ntau dhau thaum sib cuag nrog lwm cov khoom, txo cov rwb thaiv tsev hnav thiab cuam tshuam rau cov hlau txoj sia.

Khoom Sliding Properties

Huaying UL 1180 Teflon Hlau muaj ib coefficient ntawm kev sib txhuam ntawm tsuas yog 0.05 mus rau 0.15, uas yog tshwj xeeb tshaj yog tsawg rau insulated hlau. Thaum routing xov hlau hauv cov cuab yeej, txawm tias thaum rub lawv los ntawm qhov chaw kaw, lawv ntsib qhov tsis kam tsawg thiab tuaj yeem yooj yim threaded los ntawm ntau qhov sib txawv. Tsis tas li ntawd, hauv cov ntawv thov uas muaj kev sib txhuam ntawm cov xov hlau thiab lwm yam khoom siv tau tshwm sim thaum lub sijhawm ua haujlwm, xws li hauv cov khoom siv hluav taws xob ntawm cov caj npab robotic uas yuav tsum tau txav mus, qhov qis coefficient ntawm kev sib txhuam tiv thaiv kev puas tsuaj ntawm rwb thaiv tsev, tswj kev ua haujlwm zoo ib yam thiab ua kom cov khoom siv txhim khu kev qha ntau dua.

Specifications (sib series.Conventional)

Tus coj		Ua tiav sab nraud txoj kab uas hla			Conductor Resistance (20 ° C) (Ω / km)	Elongation%
Tus coj	Ua siab ntev	Yam tsawg kawg nkaus	TargetValue	MaximumValue	Conductor Resistance (20 ° C) (Ω / km)	Elongation%
0.15	0.008	0.342	0.350	0.358	1037.00	≥10%
0.16	0.008	0.352	0.360	0.368	908.80	≥10%
0.17	0.008	0.362	0.370	0.378	853.50	≥10%
0.18	0.008	0.372	0.380	0.388	757.20	≥10%
0.20	0.008	0.392	0.400	0.408	577.20	≥10%
0.21	0.008	0.402	0.410	0.418	549.00	≥10%
0.22	0.008	0.412	0.420	0.428	498.40	≥10%
0.23	0.008	0.422	0.430	0.438	454.50	≥10%
0.24	0.008	0.432	0.440	0.448	416.20	≥10%
0.25	0.008	0.442	0.450	0.458	370.20	≥10%
0.26	0.008	0.452	0.460	0.468	358.40	≥10%
0.27	0.008	0.462	0.470	0.478	331.40	≥15%
0.28	0.008	0.472	0.480	0.488	294.10	≥15%
0.29	0.008	0.482	0.490	0.498	285.70	≥15%
0.30	0.008	0.492	0.500	0.508	254.00	≥15%
0.32	0.008	0.512	0.520	0.528	222.80	≥15%
0.35	0.008	0.542	0.550	0.558	185.70	≥15%
0.37	0.008	0.562	0.570	0.578	165.90	≥15%
0.40	0.008	0.592	0.600	0.608	141.70	≥15%
0.45	0.008	0.642	0.650	0.658	112.10	≥15%
0.50	0.008	0.692	0.700	0.708	89.95	≥20%
0.55	0.008	0.742	0.750	0.758	78.15	≥20%
0.60	0.008	0.792	0.800	0.808	65.26	≥20%
0.65	0.008	0.842	0.850	0.858	55.31	≥20%
0.70	0.010	0.892	0.900	0.908	47.47	≥20%
0.75	0.010	0.942	0.950	0.958	41.19	≥20%
0.80	0.010	0.992	1.000	1.008	36.08	≥25%
0.85	0.010	1.042	1.050	1.058	31.87	≥25%
0.90	0.010	1.092	1.100	1.108	28.35	≥25%
0.95	0.010	1.142	1.150	1.158	25.38	≥25%
1.00	0.010	1.192	1.200	1.208	23.33	≥25%
