High-temperature zaj duab xis-folded hlau

Huaying High-Temperature Film-Folded Wire yog ib yam khoom ntawm Huizhou Huaying Electronic Technology Co., Ltd. Los ntawm kev sib koom tes tob nrog Shenzhen Research Institute ntawm Huazhong University of Science thiab Technology, peb tau infused cov khoom no nrog kev tshawb fawb txog kev tshawb fawb. Ob tog tau sib koom ua ke daws cov teeb meem tseem ceeb hauv thaj chaw xws li kev txhim kho cov khoom siv rwb thaiv tsev kom zoo, txhim kho qhov kub thiab txias, thiab tsim kho tus kheej-nplaum txheej tshuab. Los ntawm kev sib koom ua ke hauv tsev kawm ntawv cov kev tshawb fawb tshawb pom nrog lub tuam txhab cov kev xav tau tsim tawm, lawv tau ua tiav dhau los ntawm ntau yam kev sib tw hauv kev lag luam. Cov qauv kev sib koom ua ke no ntawm kev lag luam, kev kawm, thiab kev tshawb fawb tsis tsuas yog ua kom cov khoom tseem nyob rau hauv lub forefront ntawm kev lag luam kev ua tau zoo tab sis kuj enables teb sai sai rau kev lag luam tshiab xav tau rau high-end insulated hlau, muab kev tshawb fawb muaj zog txhawb rau kev nruam khoom iteration thiab hloov khoom dua tshiab.

Xa lus nug

Product Description

Diversified Product Solutions

Vim muaj ntau tus neeg xav tau kev pab thiab cov xwm txheej, Huaying High-Temperature Film-Folded Hlau yog tsim tshwj xeeb nrog cov thermoplastic thiab thermoset self-adhesive coatings, muab cov neeg siv khoom nrog ob txoj kev daws teeb meem. Cov ntaub ntawv thermoplastic, piv txwv li, muab kev yooj yim heev. Lawv soften thaum raug kub, cia lub kauj yuav hloov pauv - piv txwv li, kom tau raws li cov khoom siv tshwj xeeb. Thaum txias lawm, lawv tuaj yeem ruaj khov dua, ua rau lawv zoo tagnrho rau cov ntawv thov uas yuav tsum tau hloov pauv cov coil configurations. Cov ntaub ntawv thermosetting, ntawm qhov tod tes, muab cov khoom siv hluav taws xob tiv thaiv hluav taws xob zoo heev. Lawv tsuas yog poob lawv lub zog ntawm qhov kub thiab txias tshaj cov uas tuaj yeem rhuav tshem cov xim zaj duab xis, ua rau lawv tsim nyog rau cov khoom raug kub kub dhau lub sijhawm ntev. Txawm hais tias koj xaiv cov khoom twg, kev sib txuas lus yog qhov yooj yim. Muaj peb txoj hauv kev: cua kub, cua sov hauv qhov cub, lossis tsuas yog hla cov hluav taws xob tam sim no los ntawm lub kauj. Tsis muaj cov cuab yeej siv yooj yim yuav tsum tau ua, ua rau lawv yoog tau rau txhua qhov kev tsim cov coil, muab qhov tshwj xeeb yooj.

Simplified Product Processing

Qhov no Huaying High-Temperature Film-Folded Wire muaj qhov zoo dua: coil ntau lawm tshem tawm qhov xav tau ntawm cov tsoos bobbins, daim kab xev, lossis cov kua roj vanish. Rau downstream manufacturers, qhov no zoo li ib tug ntau lawm accelerator. Nyob rau hauv lub dhau los, ua coils yuav tsum xub tsim ib tug ncej, ruaj nws nrog daim kab xev, thiab thaum kawg thov cov kua roj vanish. Qhov no koom nrog ntau cov kauj ruam thiab tedious, thiab xav tau kev nqis peev tseem ceeb hauv cov ntaub ntawv ntxiv. Tam sim no, nrog rau cov hlau no, lub kauj tuaj yeem raug mob ncaj qha thiab tom qab ntawd rhaub kom ruaj ntseg, tshem tawm ntau cov kauj ruam hauv cov txheej txheem tsim khoom thiab txo cov nqi ntawm kev yuav khoom, khaws cia, thiab siv cov khoom siv ntxiv.

Ntau daim ntawv pov thawj thiab kev ua raws li ib puag ncig

Thaum nws los txog rau kev nyab xeeb thiab kev tiv thaiv ib puag ncig, Huaying High-Temperature Film-Folded Wire zoo heev. Nws tau dhau daim ntawv pov thawj kev nyab xeeb thoob ntiaj teb thiab hauv tsev xws li UL, VDE, thiab CQC. Txhua daim ntawv pov thawj ua haujlwm raws li "kev nyab xeeb dhau", uas qhia tau tias nws cov hluav taws xob ua tau zoo thiab kev tiv thaiv kev nyab xeeb muaj peev xwm ua tau raws li cov qauv kev lag luam siab. Tsis tas li ntawd, nws dhau qhov kev tshuaj xyuas ib puag ncig, nruj me ntsis ua raws li ROHS thiab REACH halogen-dawb cov qauv. Los ntawm kev tsim, siv, pov tseg, nws tso tawm tsis muaj teeb meem tshuaj, kom ntseeg tau ib puag ncig tus phooj ywg. Txawm hais tias xa tawm mus rau thoob ntiaj teb kev lag luam lossis ua cov khoom lag luam ntsuab hauv tsev, nws tuaj yeem ua tau raws li qhov yuav tsum tau ua - nws tsis tsuas yog ntxiv kev tiv thaiv rau cov cuab yeej kev nyab xeeb, tab sis kuj pab cov tuam txhab siv lub tswv yim ntawm kev tsim ntsuab. Nws yog qhov kev xaiv zoo uas siv rau hauv kev ua haujlwm, kev nyab xeeb thiab kev tiv thaiv ib puag ncig.

tus thawj coj	Ua tiav sab nraud txoj kab uas hla lub hom phiaj tus nqi	Tus neeg xyuas pib tsis kam (20 ° C) (Q2 / KM)	tus thawj coj	Ua tiav sab nraud txoj kab uas hla lub hom phiaj tus nqi	Tus neeg xyuas pib tsis kam (20 ° C) (Q2 / KM)
0.15	0.400	1037.00	0.35	0.600	185.70
0.16	0.410	908.80	0.37	0.620	165.90
0.17	0.420	853.50	0.40	0.650	141.70
0.18	0.430	757.20	0.45	0.700	112.10
0.20	0.450	577.20	0.50	0.750	89.95
0.21	0.46	549.00	0.55	0.800	78.15
0.22	0.470	498.40	0.60	0.850	65.26
0.23	0.480	454.50	0.65	0.900	55.31
0.24	0.490	416.20	0.70	0.950	47.47
0.25	0.500	370.20	0.75	1.000	41.49
0.26	0.510	358.40	0.80	1.050	36.08
0.27	0.520	331.40	0.85	1.100	31.87
0.28	0.530	294.10	0.90	1.150	28.35
0.29	0.540	285.70	0.95	1.200	25.38
0.30	0.550	254.00	1.00	1.250	23.33
0.32	0.570	222.80
