Triple Insulated Magnet Hlau

Huaying Triple Insulated Magnet Hlau yog tsim nyob rau hauv Suav teb, muab los ntawm Huizhou Huaying Electronic Technology Co., Ltd. Koj pom, peb lub tuam txhab tau tsim muaj ntau tshaj li kaum xyoo, ua rau nws yog ib hom lag luam zoo. Peb tau ntsib txoj kev loj hlob sai, thiab peb ib txwm ua raws li cov hauv paus ntsiab lus ntawm kev ncaj ncees, kev tshaj lij, thiab kev tsim kho tshiab - tsom tsis yog rau kev tsim cov khoom zoo xwb tab sis kuj tsim lub koob npe nrov. Peb siv zog ua kom muaj kev sib raug zoo nrog peb cov neeg siv khoom, tau txais txiaj ntsig ua ke, thiab tsim lub neej yav tom ntej ua ke. Cov khoom no, tom qab kev tshawb fawb thiab kev loj hlob thiab kev sim dav dav, yog cov khoom lag luam zoo. Kev txiav txim nrog kev ntseeg siab; koj yuav tsis poob siab.

Xa lus nug

Product Description

Cov khoom muaj corrosion-Resistant heev

Hauv cov teb xws li automotive electronics thiab kev tswj hwm kev lag luam, cov cuab yeej nquag tuaj rau hauv kev sib cuag nrog ntau yam tshuaj thiab muaj kev cuam tshuam rau corrosion, muab qhov tshwj xeeb xav tau ntawm cov xaim corrosion kuj. Huaying Triple Insulated Magnet Wire tau txais kev kho tshwj xeeb, ua rau muaj qhov tshwj xeeb corrosion tsis kam, ua rau nws impervious rau ntau yam kuab tshuaj thiab tshuaj. Txawm hais tias tom qab lub sij hawm ntev raug rau cov tshuaj hnyav ib puag ncig, nws cov kev ua haujlwm hluav taws xob tseem nyob ruaj khov, tsis cuam tshuam los ntawm corrosion. Qhov no ua kom ntseeg tau kev lag luam hauv cov cheeb tsam hnyav no, ua kom lub neej ntev ntawm cov cuab yeej siv tau zoo thiab ua rau nws ua haujlwm ntev, ruaj khov.

Khoom zoo heev Flexibility

Thaum tsim cov khoom siv hluav taws xob precision, qhov yooj thiab kev ruaj ntseg ntawm cov hlau yog qhov tseem ceeb. Huaying Triple Insulated Magnet Hlau yog tshwj xeeb hauv kev kho kom pom kev yooj yim. Qhov no ua rau nws yooj yim rau kev ua haujlwm nrog, tso cai rau cov neeg ua haujlwm tau yooj yim khoov thiab cua nws, zoo li cov xov mos mos. Tsis tas li ntawd, ib zaug tsim rau hauv ib lub kauj, nws cov qauv ruaj khov, tiv thaiv kev deformation los yog kev puas tsuaj los ntawm sab nraud quab yuam thaum siv, ua kom muaj kev ua tau zoo ib yam. Qhov kev sib xyaw ua ke zoo tshaj plaws ntawm kev yooj yim thiab kev ruaj ntseg ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov khoom siv hluav taws xob precision thiab ua rau muaj txiaj ntsig zoo rau cov khoom lag luam zoo ntawm cov khoom no.

Kev Pabcuam Khoom Muag Khoom

Peb lub tuam txhab tau tsim cov txheej txheem kev txhawb nqa dav dav, muab cov lus qhia thiab kev taw qhia los ntawm lub sijhawm cov neeg siv khoom pib xaiv lawv cov khoom. Nrog kev paub dhau los hauv kev lag luam insulated hlau, peb pab neeg ua haujlwm tuaj yeem nkag siab peb cov neeg siv khoom tshwj xeeb xav tau. Los ntawm kev sib koom ua ke ntau yam kev qhia tshwj xeeb thiab cov yam ntxwv ntawm Huaying Triple Insulated Magnet Wire, lawv tuaj yeem pom zoo cov qauv tsim nyog tshaj plaws, pab cov neeg siv khoom xaiv qhov yog los ntawm ntau yam kev xaiv yam tsis tas siv sijhawm. Thaum cov khoom siv, peb muab cov ncauj lus qhia ntxaws txog daim ntawv thov thoob plaws tag nrho cov txheej txheem. Txawm hais tias nws yog installation thiab commissioning, los yog ib qho teeb meem tshwm sim thaum siv, peb pab neeg technical yuav sai teb thiab muab kev daws teeb meem. Cias muab, zoo li cov kws paub txog kev paub, lawv tuaj yeem txheeb xyuas qhov teeb meem thiab muab cov kev daws teeb meem zoo. Lawv pab cov neeg siv khoom txhim kho cov khoom tsim, ua kom muaj txiaj ntsig ntawm Huaying Triple Insulated Magnet Wire, thiab ua rau lawv cov khoom sib tw. Peb pab cov neeg siv khoom ua tiav, thiab ua ke peb tsim kom muaj kev vam meej yav tom ntej.

Specifications (sib series.Conventional)

Tus coj		Ua tiav sab nraud txoj kab uas hla			Tus coj tsis kam (20 degrees Celsius) (Ω/km)	Elongation %
Tus coj	Ua siab ntev	Yam tsawg kawg nkaus Tus nqi	Hom phiaj Tus nqi	Qhov siab tshaj plaws Tus nqi	Tus coj tsis kam (20 degrees Celsius) (Ω/km)	Elongation %
0.15	0.008	0.342	0.350	0.358	1037.00	≥10%
0.16	0.008	0.352	0.360	0.368	908.80	≥10%
0.17	0.008	0.362	0.370	0.378	853.50	≥10%
0.18	0.008	0.372	0.380	0.388	757.20	≥10%
0.20	0.008	0.392	0.400	0.408	577.20	≥10%
0.21	0.008	0.402	0.410	0.418	549.00	≥10%
0.22	0.008	0.412	0.420	0.428	498.40	≥10%
0.23	0.008	0.422	0.430	0.438	454.50	≥10%
0.24	0.008	0.432	0.440	0.448	416.20	≥10%
0.25	0.008	0.442	0.450	0.458	370.20	≥10%
0.26	0.008	0.452	0.460	0.468	358.40	≥10%
0.27	0.008	0.462	0.470	0.478	331.40	≥15%
0.28	0.008	0.472	0.480	0.488	294.10	≥15%
0.29	0.008	0.482	0.490	0.498	285.70	≥15%
0.30	0.008	0.492	0.500	0.508	254.00	≥15%
0.32	0.008	0.512	0.520	0.528	222.80	≥15%
0.35	0.008	0.542	0.550	0.558	185.70	≥15%
0.37	0.008	0.562	0.570	0.578	165.90	≥15%
0.40	0.008	0.592	0.600	0.608	141.70	≥15%
0.45	0.008	0.642	0.650	0.658	112.10	≥15%
0.50	0.008	0.692	0.700	0.708	89.95	≥20%
0.55	0.008	0.742	0.750	0.758	78.15	≥20%
0.60	0.008	0.792	0.800	0.808	65.26	≥20%
0.65	0.008	0.842	0.850	0.858	55.31	≥20%
0.70	0.010	0.892	0.900	0.908	47.47	≥20%
0.75	0.010	0.942	0.950	0.958	41.19	≥20%
0.80	0.010	0.992	1.000	1.008	36.08	≥25%
0.85	0.010	1.042	1.050	1.058	31.87	≥25%
0.90	0.010	1.092	1.100	1.108	28.35	≥25%
0.95	0.010	1.142	1.150	1.158	25.38	≥25%
1.00	0.010	1.192	1.200	1.208	23.33	≥25%
